Delta ASD-A3-0421-E Servo Drive

  • Series: A3 Servo Drive
  • 400 Watts
  • 220 Volts Input
  • 1/3 Phase (PH)
  • 2.65 Arms Output Current


SPECIFICATIONS

Model Name ASD-A3-0421-E
Series A3 Servo Drive
Phase 1/3 PH
Voltage 220 VAC
Rated Output Power 0.4 kW
Continuous Output Current (Arms) 2.65 Arms
Instantaneous Max Output Current 10.61 Arms
Model Type PR Mode, EtherCAT, Full-Closed Loop Control, E-Cam, STO

CATALOG & MANUALS

Catalog Delta ASDA A3 Servo Drive Catalog
Users Manual Delta ASDA A3 Servo Drive Catalog Users Manual

SERIES DESCRIPTION

ASDA-A3 series is Delta’s newest generation servo system drive. This improves upon the ASDA-A2 seriew with finer grain control and better accuracy. The A3 drives are compatible with both A3 and A2 motors.

Features Include

  • 3.1 kHz Bandwith
  • 24-bit encoder
  • 6000 r/min motor support
  • Closed loop status control
  • Software supporting vibration suppression, auto-tuning, system diagnosis
  • STO (Safe Torque Off)
  • DC Bus Sharing
  • Smaller drive and motors compared to A2

DELTA ASD-A3-0421-E SERVO DRIVE COMPATIBLE MOTORS

Model Number Rated Output Power Rated Torque
ECM-A3H-CY0604CS1 0.4 kW 1.27 (N-m)
ECM-A3H-CY0604DS1 0.4 kW 1.27 (N-m)
ECM-A3H-CY0604PS1 0.4 kW 1.27 (N-m)
ECM-A3H-CY0604QS1 0.4 kW 1.27 (N-m)
ECM-A3H-CY0604RS1 0.4 kW 1.27 (N-m)
ECM-A3H-CY0604SS1 0.4 kW 1.27 (N-m)
ECM-A3H-C10604CS1 0.4 kW 1.27 (N-m)
ECM-A3H-C10604DS1 0.4 kW 1.27 (N-m)
ECM-A3H-C10604PS1 0.4 kW 1.27 (N-m)
ECM-A3H-C10604QS1 0.4 kW 1.27 (N-m)
ECM-A3H-C10604RS1 0.4 kW 1.27 (N-m)
ECM-A3H-C10604SS1 0.4 kW 1.27 (N-m)
ECM-A3H-CG0604CS1 0.4 kW 1.27 (N-m)
ECM-A3H-CG0604DS1 0.4 kW 1.27 (N-m)
ECM-A3H-CG0604PS1 0.4 kW 1.27 (N-m)
ECM-A3H-CG0604QS1 0.4 kW 1.27 (N-m)
ECM-A3H-CG0604RS1 0.4 kW 1.27 (N-m)
ECM-A3H-CG0604SS1 0.4 kW 1.27 (N-m)
ECM-A3H-C20604CS1 0.4 kW 1.27 (N-m)
ECM-A3H-C20604DS1 0.4 kW 1.27 (N-m)
ECM-A3H-C20604PS1 0.4 kW 1.27 (N-m)
ECM-A3H-C20604QS1 0.4 kW 1.27 (N-m)
ECM-A3H-C20604RS1 0.4 kW 1.27 (N-m)
ECM-A3H-C20604SS1 0.4 kW 1.27 (N-m)
ECM-A3H-CA0604CS1 0.4 kW 1.27 (N-m)
ECM-A3H-CA0604DS1 0.4 kW 1.27 (N-m)
ECM-A3H-CA0604PS1 0.4 kW 1.27 (N-m)
ECM-A3H-CA0604QS1 0.4 kW 1.27 (N-m)
ECM-A3H-CA0604RS1 0.4 kW 1.27 (N-m)
ECM-A3H-CA0604SS1 0.4 kW 1.27 (N-m)
ECM-A3H-CY0804C71 0.4 kW 1.27 (N-m)
ECM-A3H-CY0804D71 0.4 kW 1.27 (N-m)
ECM-A3H-CY0804P71 0.4 kW 1.27 (N-m)
ECM-A3H-CY0804Q71 0.4 kW 1.27 (N-m)
ECM-A3H-CY0804R71 0.4 kW 1.27 (N-m)
ECM-A3H-CY0804S71 0.4 kW 1.27 (N-m)
ECM-A3H-C10804C71 0.4 kW 1.27 (N-m)
ECM-A3H-C10804D71 0.4 kW 1.27 (N-m)
ECM-A3H-C10804P71 0.4 kW 1.27 (N-m)
ECM-A3H-C10804Q71 0.4 kW 1.27 (N-m)
ECM-A3H-C10804R71 0.4 kW 1.27 (N-m)
ECM-A3H-C10804S71 0.4 kW 1.27 (N-m)
ECM-A3H-CG0804C71 0.4 kW 1.27 (N-m)
ECM-A3H-CG0804D71 0.4 kW 1.27 (N-m)
ECM-A3H-CG0804P71 0.4 kW 1.27 (N-m)
ECM-A3H-CG0804Q71 0.4 kW 1.27 (N-m)
ECM-A3H-CG0804R71 0.4 kW 1.27 (N-m)
ECM-A3H-CG0804S71 0.4 kW 1.27 (N-m)
ECM-A3H-C20804C71 0.4 kW 1.27 (N-m)
ECM-A3H-C20804D71 0.4 kW 1.27 (N-m)
ECM-A3H-C20804P71 0.4 kW 1.27 (N-m)
ECM-A3H-C20804Q71 0.4 kW 1.27 (N-m)
ECM-A3H-C20804R71 0.4 kW 1.27 (N-m)
ECM-A3H-C20804S71 0.4 kW 1.27 (N-m)
ECM-A3H-CA0804C71 0.4 kW 1.27 (N-m)
ECM-A3H-CA0804D71 0.4 kW 1.27 (N-m)
ECM-A3H-CA0804P71 0.4 kW 1.27 (N-m)
ECM-A3H-CA0804Q71 0.4 kW 1.27 (N-m)
ECM-A3H-CA0804R71 0.4 kW 1.27 (N-m)
ECM-A3H-CA0804S71 0.4 kW 1.27 (N-m)
ECM-A3L-CY0604CS1 0.4 kW 1.27 (N-m)
ECM-A3L-CY0604DS1 0.4 kW 1.27 (N-m)
ECM-A3L-CY0604PS1 0.4 kW 1.27 (N-m)
ECM-A3L-CY0604RS1 0.4 kW 1.27 (N-m)
ECM-A3L-CY0604SS1 0.4 kW 1.27 (N-m)
ECM-A3L-CY0604QS1 0.4 kW 1.27 (N-m)
ECM-A3L-C10604CS1 0.4 kW 1.27 (N-m)
ECM-A3L-C10604DS1 0.4 kW 1.27 (N-m)
ECM-A3L-C10604PS1 0.4 kW 1.27 (N-m)
ECM-A3L-C10604RS1 0.4 kW 1.27 (N-m)
ECM-A3L-C10604SS1 0.4 kW 1.27 (N-m)
ECM-A3L-C10604QS1 0.4 kW 1.27 (N-m)
ECM-A3L-CG0604CS1 0.4 kW 1.27 (N-m)
ECM-A3L-CG0604DS1 0.4 kW 1.27 (N-m)
ECM-A3L-CG0604PS1 0.4 kW 1.27 (N-m)
ECM-A3L-CG0604RS1 0.4 kW 1.27 (N-m)
ECM-A3L-CG0604SS1 0.4 kW 1.27 (N-m)
ECM-A3L-CG0604QS1 0.4 kW 1.27 (N-m)
ECM-A3L-C20604CS1 0.4 kW 1.27 (N-m)
ECM-A3L-C20604DS1 0.4 kW 1.27 (N-m)
ECM-A3L-C20604PS1 0.4 kW 1.27 (N-m)
ECM-A3L-C20604RS1 0.4 kW 1.27 (N-m)
ECM-A3L-C20604SS1 0.4 kW 1.27 (N-m)
ECM-A3L-C20604QS1 0.4 kW 1.27 (N-m)
ECM-A3L-CA0604CS1 0.4 kW 1.27 (N-m)
ECM-A3L-CA0604DS1 0.4 kW 1.27 (N-m)
ECM-A3L-CA0604PS1 0.4 kW 1.27 (N-m)
ECM-A3L-CA0604RS1 0.4 kW 1.27 (N-m)
ECM-A3L-CA0604SS1 0.4 kW 1.27 (N-m)
ECM-A3L-CA0604QS1 0.4 kW 1.27 (N-m)
ECM-A3L-CY0804C71 0.4 kW 1.27 (N-m)
ECM-A3L-CY0804D71 0.4 kW 1.27 (N-m)
ECM-A3L-CY0804P71 0.4 kW 1.27 (N-m)
ECM-A3L-CY0804R71 0.4 kW 1.27 (N-m)
ECM-A3L-CY0804S71 0.4 kW 1.27 (N-m)
ECM-A3L-CY0804Q71 0.4 kW 1.27 (N-m)
ECM-A3L-C10804C71 0.4 kW 1.27 (N-m)
ECM-A3L-C10804D71 0.4 kW 1.27 (N-m)
ECM-A3L-C10804P71 0.4 kW 1.27 (N-m)
ECM-A3L-C10804R71 0.4 kW 1.27 (N-m)
ECM-A3L-C10804S71 0.4 kW 1.27 (N-m)
ECM-A3L-C10804Q71 0.4 kW 1.27 (N-m)
ECM-A3L-CG0804C71 0.4 kW 1.27 (N-m)
ECM-A3L-CG0804D71 0.4 kW 1.27 (N-m)
ECM-A3L-CG0804P71 0.4 kW 1.27 (N-m)
ECM-A3L-CG0804R71 0.4 kW 1.27 (N-m)
ECM-A3L-CG0804S71 0.4 kW 1.27 (N-m)
ECM-A3L-CG0804Q71 0.4 kW 1.27 (N-m)
ECM-A3L-C20804C71 0.4 kW 1.27 (N-m)
ECM-A3L-C20804D71 0.4 kW 1.27 (N-m)
ECM-A3L-C20804P71 0.4 kW 1.27 (N-m)
ECM-A3L-C20804R71 0.4 kW 1.27 (N-m)
ECM-A3L-C20804S71 0.4 kW 1.27 (N-m)
ECM-A3L-C20804Q71 0.4 kW 1.27 (N-m)
ECM-A3L-CA0804C71 0.4 kW 1.27 (N-m)
ECM-A3L-CA0804D71 0.4 kW 1.27 (N-m)
ECM-A3L-CA0804P71 0.4 kW 1.27 (N-m)
ECM-A3L-CA0804R71 0.4 kW 1.27 (N-m)
ECM-A3L-CA0804S71 0.4 kW 1.27 (N-m)
ECM-A3L-CA0804Q71 0.4 kW 1.27 (N-m)
Model Number Rated Output Power Rated Torque
