12″ (1024 x 768 pixels) TFT LCD 65536 colors
CE-certified aluminum enclosure
2 sets of COM ports, support RS232 / RS422 / RS485
Supports USB Host, direct connection to USB disk, printer and mouse
Supports SD card
Supports 2 Ethernet ports
Supports audio output (MP3, Wav files)
Supports video format: MPEG1, MPEG2, WMV
Touch screen complies with IP65
Supports horizontal / vertical display
PC editing software, DOPSoft is compatible with operating systems: Windows XP, Windows Vista, Windows 7
The DOP-W Series is a large Human Machine Interface (HMI) that comes with a high resolution and high brightness touch screen in 10.4”, 12” and 15” sizes. With the latest Cortex-A8 processor for up to 1GHz pulse wave, the DOP-W Series delivers high performance with rapid response. Its rugged and CE-certified aluminum enclosure protects from vibration and changing ambient temperatures, and features an IP65 waterproof front panel for harsh environments. Built-in stereo speakers increase utility and flexibility. The DOP-W Series complies with CE and UL safety approvals and provides an efficient and competitive solution to meet customer needs for a wide range of high-end industrial automation applications.
PURCHASE YOUR DELTA DOP-W127B HUMAN MACHINE INTERFACE TODAY!
