Delta DRP012V100W1AA DIN Rail Cliq Series

  • Output Voltage: 12V
  • Output Power: 100W
  • Output Current: 8.33A
  • Input Voltage Range: 85-264Vac
  • Universal AC input voltage range
  • Power will not de-rate for the entire input voltage range
This product is no longer manufactured or sold. The Delta recommended replacement is the DRF-12V120W1GBA drive. Please check the dimensions and specifications on the replacement drive page or contact us at 800-985-6929 to confirm the replacement will work for your application.

Replacement Drive

SPECIFICATIONS

Model Name DRP012V100W1AA
Series DIN Rail Power Supply
Output Voltage 12V
Output Power 100W
Input Voltage Range 85-264Vac
Output Current 8.33A
Unit Weight 0.64 kg (1.41 lb)

CATALOG & MANUALS

Catalog Delta DIN Rail Product Selection Guide
Users Manual Delta DIN Rail Manual

Features Include:

  • Universal AC input voltage range
  • Power will not de-rate for the entire input voltage range
  • Power Boost of 150% for 3 seconds
  • Full corrosion resistant aluminium casing
  • Conforms to harmonic current IEC/EN 61000-3-2, Class A
  • Multiple wire connections to terminal allowed
  • Conformal coating on PCBAs to protect against common dust and chemical pollutants
  • Hazardous Locations approval to ATEX and Class I, Div 2
  • Certified according to IEC/EN/UL 62368-1
