Delta EMM-R2CA 2-point N.C. Output Terminal Relay Card
- Add on card for MH300 VFD’s
- 2-point N.C. Output Terminal Relay Card
SPECIFICATIONS
| Terminals | Description |
|---|---|
| RA10 ~ RA11 RB10 ~ RB11 RC10 ~ RC11 |
Refer to Pr. 02-36 ~ Pr. 02-37 to program the multi-function Resistive load: 5 A (N.O.) / 240 VAC Function: To output each monitor signal, such as drive is in operation, frequency attained or overload indication |
FILES
 |
||
| Catalog | Delta MH300 Series Catalog | |
| Users Manual | Delta MH300 Series Users Manual |
PRODUCT DESCRIPTION
RA10 to RA11, RB10 to RB11, and RC10 to RC11 are programmable multi-function output terminals for monitoring signals like drive operation, frequency attained, or overload indication. They support resistive loads up to 5A at 240VAC.
