Delta TP02G-AS1 TP Series HMI Text Panel
- TP Series
- 72 x 22 mm, STN-LCD
PRODUCT SPECIFICATIONS
| Model Name | TP02G-AS1 |
| Series | TP Series |
| Display Size and Type | 72 x 22 mm, STN-LCD |
| Display Colors | Monochrome |
| Resolution (pixels) | 160 x 32 |
| Flash ROM (Bytes) | 256k |
| COM1 | RS-232 |
| COM2 | RS-485 |
| IP Level | IP66/NEMA 4x /UL Type 4x |
| Dimensions | 5.78 (in) x 3.81 (in) x 1.39 (in) |
FILES
 | |
| Catalog | Delta TP Series Catalog |
| Dimensions | Delta TP02G-AS1 Dimensions |
| Instruction Sheet | Delta TP02G-AS1 Instruction Sheet |
| 2D CAD | Delta TP02G-AS1 2D CAD |
| 3D CAD | Delta TP02G-AS1 3D CAD |
| Software | Delta TP Editor Software |
SERIES DESCRIPTION
Delta’s Text Panel HMI series is a monochrome text and graphics panel with a built in PLC. Delta Text Panels are known for simple operation and control functions. The series supports various communication protocols and ports that vary per model. It has the advantages of light weight, low price and good flexibility allowing the users to quickly program systems.
