Delta DOP-B03E211 DOP-B Series HMI Touchscreen

  • DOP-B Series HMI Touchscreen
  • 4.3 Inches Display Size
  • 480 X 272 Pixel Resolution
  • 24 Volts Input
This product is no longer manufactured or sold. The Delta recommended replacement is the DOP-103WQ drive. Please check the dimensions and specifications on the replacement panel page or contact us at 800-985-6929 to confirm the replacement will work for your application.

Replacement


We provide all Delta AC Drives, VFD’s,  Delta AC Servo Motors, Delta Rotary Optical Encoders, Delta Motion Control Network, Delta Programmable Logic Controller, Delta Human Machine Interfaces, Delta Text Panels, Delta Temperature Controllers, Delta Industrial Fieldbus Solutions, Delta Pressure Sensor, Delta Brushless DC Motors as well as Delta Brushless DC Drives.

Specifications

4.3-inch (480 x 272 pixels) TFT LCD 65536 colors
2 sets of COM ports, supports RS-232 / RS-422 / RS-485
For data transfer/download: RS-232, USB, Ethernet
Supports Ethernet
Complies with IP65 standard
Supports horizontal / vertical display
PC editing software, DOPSoft is compatible with operating systems: Windows XP, Windows Vista, Windows 7

DOP-B Series

The DOP Series Human Machine Interface (HMI) provides various touch screens with multiple dimensions and colors. It also offers fast and convenient control functions for industrial automation machines. In addition, Delta Windows-based and user-friendly DOPSoft Screen Editor and Programming Software configures the whole DOP Series. With DOPSoft, users can quickly edit images and graphs and easily set suitable communication protocol. More applications can be created, edited, downloaded and uploaded.

Downloads:

Delta DOP-B-User-Manual

Delta DOP-B-Catalog

PURCHASE YOUR DELTA DOP-B03E211 HUMAN MACHINE INTERFACE TODAY!
