SPECIFICATIONS
Model Name | DRF-48V240W1GBA |
Series | DIN Rail Power Supply |
Output Voltage | 48V |
Input Voltage Range | 90-264 Vac |
Output Current | 5A |
Output Power | 240W |
CATALOG & MANUALS
Catalog | Delta DIN Rail Product Selection Guide | |
Users Manual | Delta DIN Rail Manual |
Features Include:
- Universal AC input voltage range
- Built-in constant current circuit for charging applications
- Full load operating temperature up to 60°C
- Cold start at -40°C
- Ultra-Slim design
- Long life electrolytic capacitor
- Built-in DC OK relay and LED indicator
- Conformal coating on PCBAs to protect against common dust and pollutants
