Delta VFD022EL21W(-1) VFD-EL-W Series
- Series: EL-W
- 2 HP
- 2.2 KW
- 11 A
- 230 V
- Input: 1 PH
SPECIFICATIONS
| Model Name | VFD022EL21W(-1) |
| Series | VFD-EL-W Series |
| Input Voltage – Phase | 230 V – 1 Phase |
| Motor Power Range | 2.2 KW – 3 HP – 11A |
| Weight | 2.2 lbs |
| Dimensions | 3.94 in (W) x 3.5 in (H) x 6.85 in (D) |
CATALOG & MANUALS
 |
||
| Catalog | Delta EL-W Series Catalog | |
| Users Manual | Delta EL-W Series Users Manual |
SERIES DESCRIPTION
Delta’s VFD-EL-W series is the new generation compact vector control drive. Simple, delicate and durable design inherits Delta’s superior drive technology.
Various essential functions are built-in as standard, including: Multi-step Operation; Torque Compensation; PID Control; Multi-Pump Control; Water Supply at Constant Pressure; Leakage Detection function and so on.
Features Include:
Simple Speed Control
Horizontal Movement
Fixed Load Applications
Safety and Reliability
150 % / 60 secs overload capability | Energy-saving | CE certification
Easy Maintenance
Natural cooling | Fan Cooling
Complete Functions
Single / multi-pump control: constant pressure mode & alternative operation | Built-in PID feedback control | Protection: overload, over voltage / over current stall prevention
